https://youtu.be/klwzae3YE6Y?t=332 - program for circuit

Shift + Key (1 to 16) Select user channel and reset Kbd Play Midi channel
Shift + Oct Plus + Key Selects Midi channel for Kbd play mode

Sequencer

Sequencer mode

stop is LED = normal mode
knob 1 - chose seq
knob 2 change division / (with shift wait to release shift)
time division (how many in one click)

Record mode:

To enable recording click Record red led will appear (Shift + Record append)

Record one step: click Key
Record pause: click Tab to record pause
Record Linked notes: click Key and Tab while clicked
Record Legato notes: Tab and sequence of Keys (slide to next node)
Delete last step of the sequence: Shift + STOP (only in Seq mode)
Stop to finish
Play to play (Play + Shift - play from begining)
Reset: Shift + Octave Up + Octave Down Reset sequence content

Record + 16 first keys Set the sequence length
[ARP] Shift + Octave buttons Add or remove octaves in the arpeggio
Shift + Rate Tempo fine-tune

Chord node

Chord mode: [Hold] Shift + hold

play up to 16 notes (can be one by one). U can record chords. (cannot store in bank)

Shift + HOLD Enter/Exit chord mode Shift + HOLD + Keys Enter new notes for the chord mode (Hold button blinks quickly)

Transpose / Play Keys

can play both to 2 devices

transpose- Shift + - oct

play -shift + + oct

Arpeggiator

play every key in loop

Style

gate - shift + key (not working with linked and legato )
swing - shift + key

Settings

Reset - Oct+ and Oct- while powering up - You should have an additional LED pattern, release the buttons once it’s over. This will also reset your global parameters (the ones you set into the MCC).
